Our high-performance, low power single board computers are designed, manufactured and tested on-site, and when combined with our extensive experienced technical support, can save you time and money in your product development.
We produce a range of ‘off-the-shelf’ SBCs that feature some configurable elements, providing enough flexibility for most applications. Alternatively, if our off-the-shelf single board computers do not suit your requirements, we can design a custom solution just for you at a lower cost and commitment than you might expect.
We use the latest components and advanced technologies, as well as provide ongoing support, to ensure our products are highly reliable and available for many years to come. We regularly produce SBCs for both benign and harsh industrial environments. Our experience in a wide variety of markets – aerospace, medical, oil & gas and rail, for example – means we have an understanding of your product requirements and the characteristics of the environment within which it will be used.
-
TM3+HB8/9
Full featured quad core single board computer
- Computer-on-Module and Carrier Board combination
- Supports HDMI 2.0b, 4.3″, 7.1″, 9.7″ & 12” TFT LCDs
- Supports Projected Capacitive or Resistive touchscreens
- USB 3.0 & 2.0 Host and Device ports, 12 digital input & outputs
- M.2 Key B, PCIe & USB
- 10/100 Mbit Ethernet
- Dual RS232 Ports plus single RS232/422/485 port
- Stereo audio inputs & outputs and audio amplifier
- Vertical I/O to minimise width
-
TM3+HB8/9 LT
Quad core single board computer
- Computer-on-Module and Carrier Board combination
- Supports 4.3″, 7.1″, 9.7″ & 12” TFT LCDs
- Supports Projected Capacitive or Resistive touchscreens
- USB 2.0 Host and Device ports, 12 digital input & outputs
- 10/100 Mbit Ethernet
- Dual RS232 Ports plus single RS232/422/485 port
- Stereo audio inputs & outputs and audio amplifier
- Vertical I/O to minimise width
-
DB1
Ultra compact quad core module with integrated Wifi and GPS capability
- Single board computer
- Supports HDMI 2.0b, 4.3″, 7.1″, 9.7″ & 12” TFT LCDs
- Supports Projected Capacitive or Resistive touchscreens
- USB 2.0 Host and Device ports, 12 digital input & outputs
- 10/100/1000 Mbit Ethernet
- Dual RS232 Ports plus single RS232/422/485 port
- Stereo audio inputs & outputs and audio amplifier
- Vertical I/O to minimise width
-
TM3+HB10
Host board for TM3, offering isolated inputs, outputs and CAN FD / 2.0b
- Computer-on-Module and Carrier Board combination
- Supports HDMI 2.0b, 4.3″, 7.1″, 9.7″ & 12” TFT LCDs
- Supports Projected Capacitive or Resistive touchscreens
- 2 USB 2.0 Host and 1 USB 2.0 Device ports
- 8 isolated digital input & 8 isolated outputs
- Isolated CAN FD / 2.0B interface
- 10/100 Mbit Ethernet
- Dual RS232 Ports plus single RS232/422/485 port
- Stereo audio 10W audio amplifier
-
TM1 + HB5
ARM Cortex A9 Single Board Computer
- Computer-on-Module and Carrier Board combination
- Supports 4.3″, 7.1″ and 9.7″ TFT LCDs
- Supports Projected Capacitive or Resistive touchscreens
- USB 2.0 Host and Device ports, 12 digital input & outputs
- 10/100 Mbit Ethernet
- Dual RS232 Ports plus single RS232/422/485 port
- Stereo audio inputs & outputs and audio amplifier
- Horizontal I/O on carrier board
-
TM1 + HB6
ARM Cortex A9 Single Board Computer
- Computer-on-Module and Carrier Board combination
- Supports 4.3″, 7.1″ and 9.7″ TFT LCDs
- Supports Projected Capacitive or Resistive touchscreens
- USB 2.0 Host and Device ports, 12 digital input & outputs
- 10/100 Mbit Ethernet
- Dual RS232 Ports plus single RS232/422/485 port
- Stereo audio inputs & outputs and audio amplifier
- Vertical I/O to minimise width
-
XE1
High-performance x86 SBC.
- Run your existing Windows-based applications on this x86 / x64 SBC.
- Passively cooled, ideal for low-power products.
- Radeon graphics supporting DirectX 11.2.
- Dual-core, AMD G-Series CPU.
- WiFi, Bluetooth and 3G available via expansion headers.
- M.2 SATA SSD storage options.
- Available for at least 10 years.
-
RE3
ARM Cortex A9 Single Board Computer
- High-performance, high-integration single board computer
- Dual / Quad-Core Cortex A9 CPU
- 1GB DDR3 Memory, 2GB Option, 1GB NAND Flash plus uSD Socket for more storage
- H.264 1080p60 decode, 1080p30 encode and 3-D video playback in HD
- Two independent video outputs – HDMI and 24-bit LCD
- LAN, CAN 2.0 Port, 12 off GPIO signals, I2C, SATA, Mini PCIe
- SIM Socket for 2G/3G/4G Modem operation
- Two NTSC/PAL/SECAM Composite Camera inputs
-
RM3+HB3 EVAL
ARM Cortex A8 Single Board Computer
- Highly-integrated single board computer
- TI AM3730 1GHz ARM Cortex A8 with 800MHz C64x DSP
- ARM NEON Floating Point
- 256MB Low Power DDR Memory, 512MB NAND Flash
- 4x USB 2.0 host ports, 1x USB 2.0 device port
- 2x RS232 and RS485 serial ports, I2C, SPI, GPIO channels, Camera port
- Onboard Wi-Fi and Bluetooth with UFL connectors
- DVI/HDMI, RGB (TTL/CMOS), LVDS
-
RE2G2
ARM Cortex A8 Single Board Computer
- Highly-integrated single board computer
- TI AM3730 1GHz ARM Cortex A8 with 800MHz C64x DSP
- ARM NEON Floating Point
- 256MB Low Power DDR Memory, 512MB NAND Flash
- 4x USB 2.0 host ports, 1x USB 2.0 device port
- 2x RS232 and RS485 serial ports, I2C, SPI, GPIO channels, Camera port
- Onboard Wi-Fi and Bluetooth with UFL connectors
- DVI/HDMI, RGB (TTL/CMOS), LVDS
